Description
Technical specifications
- Lamp category: LED CoB
- Power (W): 7W / 9W / 12W / 15W
- CCT (K): 2700K / 3000K / 4000K
- CRI:≥90
- Color consistency: < 3 SDCM
- Initial lumens (lm): 700 / 900 / 1200 / 1500 lm
- Net lumens (lm): 620 / 810 / 1020 / 1250 lm
- Mountings: Ceiling recessed Trim
- Environment: Indoor dry location
- L80B20 lifespan: 50,000h at Tp
Optical Parameters
- Lighting type: Direct
- LED type: Power LED
- Light distribution: Symmetric
- Optical type: Downlight
- Beam angle (°): 15 / 24 / 38 Deg
Electrical Parameters
- Frequency (Hz): 50/60
- Dimmable: Available
- Driver: Remote included (Non Dim)
- Driver type: Dimmable 1-10V, Dimmable DALI 1
- Emergency: Without
- Insulation class: II
Physical Parameters
- Trim Color: White | Black
- Reflector: Specular Chrome / White / Black / Matt Chrome
- Orientation: Adjustable
- Recessed depth (mm): 76 / 93
- Dia (mm) : 85
- Cutout (mm) : 75
- Weight (kg): 0.38
